- دیتاشیت TPS70302PWPR
TPS70302PWPR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | TPS70302PWPR |
|---|---|
| حجم فایل | 91.983 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 46 |
دانلود دیتاشیت TPS70302PWPR |
دانلود دیتاشیت |
|---|
سایر مستندات
TPS70345/48/51/58/02 47 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments TPS70302PWPR
- Output Type: Adjustable
- Output Current: 1A;2A
- Output Voltage: 1.22V~5.5V
- Dropout Voltage: 250mV@(1A);-
- Output Polarity: Positive
- Number of Outputs: 2
- Maximum Input Voltage: 6V
- Power Supply Rejection Ratio (PSRR): 65dB@(1kHz);60dB@(1kHz)
- Package: HTSSOP-24
- Manufacturer: Texas Instruments
- Operating Temperature: -40°C ~ 125°C
- Base Part Number: TPS703
- Supplier Device Package: 24-HTSSOP
- Voltage - Output (Max): 5.5V
- Output Configuration: Positive
- Current - Quiescent (Iq): 250µA
- PSRR: 65dB (1kHz), 60dB (1kHz)
- Voltage Dropout (Max): 0.25V @ 1A, -
- Number of Regulators: 2
- Mounting Type: Surface Mount
- Packaging: Cut Tape (CT)
- Voltage - Output (Min/Fixed): 1.22V
- Protection Features: Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
- Series: -
- Voltage - Input (Max): 6V
- Current - Output: 1A, 2A
- Part Status: Active
- Package / Case: 24-TSSOP (0.173", 4.40mm Width) Exposed Pad
- Control Features: Enable, Power Good, Reset, Sequencing
- detail: Linear Voltage Regulator IC 2 Output 1A, 2A 24-HTSSOP
