TPS77501MPWPREP دیتاشیت

TPS77501MPWPREP

مشخصات دیتاشیت

نام دیتاشیت TPS77501MPWPREP
حجم فایل 124.256 کیلوبایت
نوع فایل pdf
تعداد صفحات 26

دانلود دیتاشیت TPS77501MPWPREP

دانلود دیتاشیت

سایر مستندات

TPS77501/15/16/18/25/33-EP 26 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Texas Instruments TPS77501MPWPREP
  • Package: TSSOP-20-EP
  • Manufacturer: Texas Instruments
  • Operating Temperature: -55°C ~ 125°C
  • Base Part Number: TPS775
  • Supplier Device Package: 20-HTSSOP
  • Voltage - Output (Max): 5.5V
  • Output Configuration: Positive
  • Current - Quiescent (Iq): 125µA
  • Output Type: Adjustable
  • PSRR: 60dB (100Hz)
  • Voltage Dropout (Max): -
  • Number of Regulators: 1
  • Mounting Type: Surface Mount
  • Packaging: Cut Tape (CT)
  • Voltage - Output (Min/Fixed): 1.5V
  • Protection Features: Over Current, Over Temperature, Reverse Polarity
  • Series: -
  • Voltage - Input (Max): 10V
  • Current - Output: 500mA
  • Part Status: Active
  • Package / Case: 20-PowerTSSOP (0.173", 4.40mm Width)
  • Control Features: Enable, Reset
  • detail: Linear Voltage Regulator IC 1 Output 500mA 20-HTSSOP
