UCC12040 دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | UCC12040 |
|---|---|
| حجم فایل | 1975.037 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 34 |
دانلود دیتاشیت UCC12040 |
دانلود دیتاشیت |
|---|
سایر مستندات
مشخصات فنی
- Type: Isolated Module
- Voltage - Output 2: -
- Voltage - Output 3: -
- Applications: ITE (Commercial), Laboratory, Medical
- Approval Agency: CQC, TUV, UL, VDE
- Series: -
- Packaging: Cut Tape (CT)
- Voltage - Isolation: 3kV
- Voltage - Output 4: -
- Current - Output (Max): 140mA, 100mA
- Voltage - Output 1: 3.3V, 5V
- Manufacturer: Texas Instruments
- Supplier Device Package: 16-SOIC
- Voltage - Input (Min): 4.5V
- Power (Watts): 500mW
- Size / Dimension: 0.41" L x 0.30" W x 0.10" H (10.3mm x 7.5mm x 2.7mm)
- Base Part Number: UCC12040
- Features: -
- Efficiency: 60%
- Package / Case: 16-SOIC (0.295", 7.50mm Width)
- Mounting Type: Surface Mount
- Voltage - Input (Max): 5.5V
- Number of Outputs: 1
- Part Status: Active
- Control Features: Enable, Active High
- Operating Temperature: -40°C ~ 125°C (With Derating)
- detail: Isolated Module DC DC Converter 1 Output 3.3V, 5V 140mA, 100mA 4.5V - 5.5V Input
