CC1352R1F3RGZR دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت CC1352R1F3RGZR	دانلود دیتاشیت

RoHS: true
Category: Radio Frequency Chip/Antenna/RF Transceiver ICs
Data Rate: 250Kbps
Datasheet: Texas Instruments CC1352R1F3RGZR
Interface: I2C,I2S,SPI,UART
Applications: Bluetooth
Frequency Range: 287MHz~351MHz;2.36GHz~2.5GHz
Receive Current: 5.8mA
Operating Voltage: 1.8V~3.8V
Operating Temperature: -40°C~+85°C
Current Of Transmitting: 7.1mA
Package: QFN-48-EP(7x7)
Manufacturer: Texas Instruments
Type: TxRx + MCU
Data Rate (Max): 250kbps
Series: SimpleLink™
Protocol: Bluetooth v5.1, Thread, Zigbee®
Memory Size: 352kB Flash, 80kB RAM
GPIO: 28
Sensitivity: -110dBm
Packaging: Cut Tape (CT)
Voltage - Supply: 1.8V ~ 3.8V
Supplier Device Package: 48-VQFN (7x7)
Frequency: 287MHz ~ 351MHz, 359MHz ~ 527MHz, 861MHz ~ 1.054GHz, 1.076GHz ~ 1.315GHz, 2.36GHz ~ 2.5GHz
Current - Receiving: 5.8mA ~ 6.9mA
Power - Output: 14dBm
Modulation: 2-FSK, 4-FSK, GFSK
Current - Transmitting: 7.1mA ~ 24.9mA
Base Part Number: CC1352
Serial Interfaces: I²C, I²S, SPI, UART
Package / Case: 48-VFQFN Exposed Pad
Mounting Type: Surface Mount
RF Family/Standard: Bluetooth
Part Status: Active
detail: IC RF TxRx + MCU Bluetooth Bluetooth v5.1, Thread, Zigbee® 287MHz ~ 351MHz, 359MHz ~ 527MHz, 861MHz ~ 1.054GHz, 1.076GHz ~ 1.315GHz, 2.36GHz ~ 2.5GHz 48-VFQFN Exposed Pad
