دیتاشیت STP8NM60
مشخصات دیتاشیت
| نام دیتاشیت | STD5NM60, STB8NM60, STP8NM60 |
|---|---|
| حجم فایل | 567.812 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 18 |
دانلود دیتاشیت STD5NM60, STB8NM60, STP8NM60 |
STD5NM60, STB8NM60, STP8NM60 Datasheet |
|---|
مشخصات
- Manufacturer: STMicroelectronics
- Series: MDmesh™
- Packaging: Tube
- Part Status: Obsolete
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 650V
- Current - Continuous Drain (Id) @ 25°C: 8A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 10V
- Rds On (Max) @ Id, Vgs: 1Ohm @ 2.5A, 10V
- Vgs(th) (Max) @ Id: 5V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs: 18nC @ 10V
- Vgs (Max): ±30V
- Input Capacitance (Ciss) (Max) @ Vds: 400pF @ 25V
- FET Feature: -
- Power Dissipation (Max): 100W (Tc)
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Through Hole
- Supplier Device Package: TO-220AB
- Package / Case: TO-220-3
- Base Part Number: STP8N
- detail: N-Channel 650V 8A (Tc) 100W (Tc) Through Hole TO-220AB
