Power Through the Isolation Barrier دیتاشیت

Power Through the Isolation Barrier

مشخصات دیتاشیت

نام دیتاشیت Power Through the Isolation Barrier
حجم فایل 924.573 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

مشاهده دیتاشیت Power Through the Isolation Barrier

دانلود دیتاشیت

سایر مستندات

UCC12050 34 pages

UCC12050DVER 34 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/DC-DC Converters
  • Datasheet: Texas Instruments UCC12050DVER
  • Package: SOP-16-300mil
  • Manufacturer: Texas Instruments
  • Type: Isolated Module
  • Voltage - Output 2: -
  • Voltage - Output 3: -
  • Applications: ITE (Commercial), Laboratory, Medical
  • Approval Agency: CQC, TUV, UL, VDE
  • Series: -
  • Packaging: Cut Tape (CT)
  • Voltage - Isolation: 5kV
  • Voltage - Output 4: -
  • Current - Output (Max): 140mA, 100mA
  • Voltage - Output 1: 3.3V, 5V
  • Supplier Device Package: 16-SOIC
  • Voltage - Input (Min): 4.5V
  • Power (Watts): 500mW
  • Size / Dimension: 0.41" L x 0.30" W x 0.10" H (10.3mm x 7.5mm x 2.7mm)
  • Base Part Number: UCC12050
  • Features: Remote On/Off
  • Efficiency: 60%
  • Package / Case: 16-SOIC (0.295", 7.50mm Width)
  • Mounting Type: Surface Mount
  • Voltage - Input (Max): 5.5V
  • Number of Outputs: 1
  • Part Status: Active
  • Control Features: Enable, Active High
  • Operating Temperature: -40°C ~ 125°C (With Derating)
  • detail: Isolated Module DC DC Converter 1 Output 3.3V, 5V 140mA, 100mA 4.5V - 5.5V Input
