دیتاشیت DAC38J84IAAV

DAC37J84,DAC38J84

مشخصات دیتاشیت

نام دیتاشیت DAC37J84,DAC38J84
حجم فایل 2744.197 کیلوبایت
نوع فایل pdf
تعداد صفحات 121

دانلود دیتاشیت DAC37J84,DAC38J84

DAC37J84,DAC38J84 Datasheet

مشخصات

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
  • Datasheet: Texas Instruments DAC38J84IAAV
  • Resolution: 16Bit
  • Output Type: Current-非缓冲
  • Settling Time: 10ns
  • Supply Voltage: 0.85V~0.95V
  • Integral nonlinearity: ±6LSB;±4LSB
  • Operating Temperature: -40°C~+85°C
  • Package: FCBGA-144(10x10)
  • Manufacturer: Texas Instruments
  • Voltage - Supply, Analog: 3.15V ~ 3.45V
  • Supplier Device Package: 144-FCBGA (10x10)
  • Data Interface: JESD204B
  • Number of D/A Converters: 4
  • Mounting Type: Surface Mount
  • Number of Bits: 16
  • Architecture: Current Source
  • Voltage - Supply, Digital: 0.85V ~ 0.95V
  • Packaging: Tray
  • Differential Output: Yes
  • Reference Type: External, Internal
  • Series: -
  • Package / Case: 144-FBGA, FCBGA
  • INL/DNL (LSB): ±6, ±4
  • Base Part Number: DAC38J84
  • Part Status: Active
  • detail: 16 Bit Digital to Analog Converter 4 144-FCBGA (10x10)
