دیتاشیت REF5020MDREP
مشخصات دیتاشیت
| نام دیتاشیت | REF50xx-EP Datasheet |
|---|---|
| حجم فایل | 1860.173 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 30 |
دانلود دیتاشیت REF50xx-EP Datasheet |
REF50xx-EP Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Voltage References
- Datasheet: Texas Instruments REF5020MDREP
- Tolerance: ±0.05%
- Output Type: Fixed
- Input Voltage: 2.7V~18V
- Output Current: 10mA
- Output Voltage: 2.048V
- Reference Type: series connection
- Supply Current: 1.25mA
- Noise - 10Hz to 10kHz: -
- Operating Temperature: -55°C~+125°C@(Ta)
- Noise - 1/10Hz to 10Hz: 6uVp-p
- Temperature Coefficient: 5ppm/°C
- Package: SOP-8
- Manufacturer: Texas Instruments
- Base Part Number: REF502
- Supplier Device Package: 8-SOIC
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Current - Supply: 1.25mA
- Part Status: Active
- Mounting Type: Surface Mount
- Packaging: Cut Tape (CT)
- Voltage - Output (Min/Fixed): 2.048V
- Series: -
- Voltage - Input: 2.7V ~ 18V
- Current - Output: 10mA
- Noise - 0.1Hz to 10Hz: 6µVp-p
- detail: Series Voltage Reference IC ±0.05% 8-SOIC
