RBO40-40T 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: STMicroelectronics
- Series: RBO
- Packaging: Tube
- Part Status: Obsolete
- Type: Zener
- Unidirectional Channels: 1
- Bidirectional Channels: 1
- Voltage - Reverse Standoff (Typ): 20V
- Voltage - Breakdown (Min): 24V
- Voltage - Clamping (Max) @ Ipp: 40V
- Current - Peak Pulse (10/1000µs): 20A, 37.5A
- Power - Peak Pulse: 1500W (1.5kW)
- Power Line Protection: No
- Applications: General Purpose
- Capacitance @ Frequency: -
- Operating Temperature: -40°C ~ 150°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-220-3
- Supplier Device Package: TO-220AB
- Base Part Number: RBO40
- detail: 40V Clamp 20A, 37.5A Ipp Tvs Diode Through Hole TO-220AB
