- MSP430xG461x Datasheet
MSP430xG461x Datasheet Datasheet
Datasheet specifications
| Datasheet's name | MSP430xG461x Datasheet |
|---|---|
| File size | 2464.335 KB |
| File type | |
| Number of pages | 116 |
Download Datasheet MSP430xG461x Datasheet |
Download Datasheet |
|---|
Other documentations
Technical specifications
- RoHS: true
- EEPROM: -
- CPU Core: MSP430
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: -
- Watchdog: Yes
- ADC (Bit): 12bit
- DAC (Bit): 12bit
- Datasheet: Texas Instruments MSP430FG4616IPZR
- PWM (Bit): -
- LCD Module: Yes
- Real-Time Clock: -
- CPU Maximum Speed: 8MHz
- GPIO Ports Number: 80
- Low-Voltage Detect: Yes
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: DMA;LCD/LED Driver
- Program Memory Type: -
- Direct Memory Access: Yes
- Program Storage Size: 92KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 1.8V~3.6V
- Infrared Data Association: Yes
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: LQFP-100(14x14)
- Manufacturer: Texas Instruments
- Series: MSP430x4xx
- EEPROM Size: -
- Oscillator Type: Internal
- Mounting Type: Surface Mount
- Peripherals: Brown-out Detect/Reset, DMA, LCD, POR, PWM, WDT
- Data Converters: A/D 12x12b; D/A 2x12b
- Packaging: Cut Tape (CT)
- Core Processor: CPUX
- Number of I/O: 80
- Program Memory Size: 92KB (92K x 8 + 256B)
- Core Size: 16-Bit
- Connectivity: I²C, IrDA, LINbus, SCI, SPI, UART/USART
- Voltage - Supply (Vcc/Vdd): 1.8V ~ 3.6V
- Supplier Device Package: 100-LQFP (14x14)
- Base Part Number: 430FG4616
- Package / Case: 100-LQFP
- Speed: 8MHz
- Part Status: Active
- Operating Temperature: -40°C ~ 85°C (TA)
- detail: CPUX MSP430x4xx Microcontroller IC 16-Bit 8MHz 92KB (92K x 8 + 256B) FLASH 100-LQFP (14x14)
