دیتاشیت VIPER50A(022Y)

VIPer50/SP, VIPer50A/ASP

مشخصات دیتاشیت

نام دیتاشیت VIPer50/SP, VIPer50A/ASP
حجم فایل 435.484 کیلوبایت
نوع فایل pdf
تعداد صفحات 23

دانلود دیتاشیت VIPer50/SP, VIPer50A/ASP

VIPer50/SP, VIPer50A/ASP Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: VIPER™
  • Packaging: Tube
  • Part Status: Obsolete
  • Output Isolation: Isolated
  • Internal Switch(s): Yes
  • Voltage - Breakdown: 700V
  • Topology: Flyback
  • Voltage - Start Up: 11V
  • Voltage - Supply (Vcc/Vdd): 8V ~ 15V
  • Duty Cycle: -
  • Frequency - Switching: Up to 200kHz
  • Power (Watts): 50W
  • Fault Protection: Current Limiting, Over Temperature
  • Control Features: Frequency Control, Soft Start, Sync
  • Operating Temperature: -
  • Package / Case: Pentawatt-5 HV (Bent and Staggered Leads)
  • Supplier Device Package: 5-PENTAWATT
  • Mounting Type: Surface Mount
  • Base Part Number: VIPER50
  • detail: Converter Offline Flyback Topology Up to 200kHz 5-PENTAWATT
