دیتاشیت VN750-B5
مشخصات دیتاشیت
| نام دیتاشیت |
VN750
|
| حجم فایل |
747.443
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
46
|
مشخصات
-
Manufacturer:
STMicroelectronics
-
Series:
VIPower™
-
Packaging:
Tube
-
Part Status:
Obsolete
-
Switch Type:
General Purpose
-
Number of Outputs:
1
-
Ratio - Input:Output:
1:1
-
Output Configuration:
High Side
-
Output Type:
N-Channel
-
Interface:
On/Off
-
Voltage - Load:
5.5V ~ 36V
-
Voltage - Supply (Vcc/Vdd):
Not Required
-
Current - Output (Max):
6A
-
Rds On (Typ):
60mOhm (Max)
-
Input Type:
Non-Inverting
-
Features:
Auto Restart, Status Flag
-
Fault Protection:
Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
-
Operating Temperature:
-40°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
P2PAK
-
Package / Case:
P²PAK (4 Leads + Tab)
-
Base Part Number:
VN750
-
detail:
Power Switch/Driver 1:1 N-Channel 6A P2PAK
