دیتاشیت ST1394-01SC6

ST1394

مشخصات دیتاشیت

نام دیتاشیت ST1394
حجم فایل 171.131 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

دانلود دیتاشیت ST1394

ST1394 Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: IPAD™
  • Packaging: Cut Tape (CT)
  • Part Status: Obsolete
  • Type: Low Pass
  • Filter Order: 2nd
  • Technology: RC (Pi)
  • Number of Channels: 2
  • Center / Cutoff Frequency: -
  • Attenuation Value: -
  • Resistance - Channel (Ohms): 55
  • Values: R = 55Ohms, C = 250pF (Total)
  • ESD Protection: Yes
  • Operating Temperature: -
  • Applications: Data Lines for Mobile Devices
  • Voltage - Rated: -
  • Mounting Type: Surface Mount
  • Package / Case: SOT-23-6
  • Size / Dimension: 0.115" L x 0.064" W (2.93mm x 1.63mm)
  • Height: 0.057" (1.45mm)
  • Base Part Number: ST1394
  • detail: RC (Pi) EMI Filter 2nd Order Low Pass 2 Channel R = 55Ohms, C = 250pF (Total) SOT-23-6
