Analog Signal Chain Guide دیتاشیت

Analog Signal Chain Guide

مشخصات دیتاشیت

نام دیتاشیت Analog Signal Chain Guide
حجم فایل 1059.19 کیلوبایت
نوع فایل pdf
تعداد صفحات 11

دانلود دیتاشیت Analog Signal Chain Guide

دانلود دیتاشیت

سایر مستندات

DAC8718 66 pages

TI DAC8718SRGZT 67 pages

مشخصات فنی

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
  • Datasheet: Texas Instruments DAC8718SRGZT
  • Interface: SPI
  • Resolution: 16Bit
  • Output Type: Voltage-缓冲
  • Settling Time: 15us
  • Supply Voltage: 2.7V~5.5V
  • Integral nonlinearity: ±4LSB;±1LSB
  • Operating Temperature: -40°C~+105°C
  • Package: QFN-48-EP(7x7)
  • Manufacturer: Texas Instruments
  • Voltage - Supply, Analog: 9V ~ 36V, ±4.5V ~ 18V
  • Supplier Device Package: 48-VQFN (7x7)
  • Data Interface: SPI
  • Number of D/A Converters: 8
  • Mounting Type: Surface Mount
  • Number of Bits: 16
  • Architecture: String DAC
  • Voltage - Supply, Digital: 2.7V ~ 5.5V
  • Packaging: Cut Tape (CT)
  • Differential Output: No
  • Reference Type: External
  • Series: -
  • Package / Case: 48-VFQFN Exposed Pad
  • INL/DNL (LSB): ±4 (Max), ±1 (Max)
  • Base Part Number: DAC8718
  • Part Status: Active
  • detail: 16 Bit Digital to Analog Converter 8 48-VQFN (7x7)
