ADS52J90ZZE دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | ADS52J90ZZE |
|---|---|
| حجم فایل | 92.123 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 153 |
دانلود دیتاشیت ADS52J90ZZE |
دانلود دیتاشیت |
|---|
سایر مستندات
ADS52J90 Datasheet 152 pages
مشخصات فنی
- RoHS: true
- Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
- Datasheet: Texas Instruments ADS52J90ZZE
- Interface: serial
- resolution: 14Bit
- Supply Voltage: 1.7V~1.9V
- differential input: Yes
- number of channels: 8;16;32
- sampling frequency: 100MHz
- Operating Temperature: -40°C~+85°C
- Package: NFBGA-198(9x15)
- Manufacturer: Texas Instruments
- Architecture: Pipelined
- Sampling Rate (Per Second): 100M
- Series: -
- Voltage - Supply, Analog: 1.7V ~ 1.9V
- Input Type: Differential
- Number of A/D Converters: 16
- Number of Bits: 14
- Voltage - Supply, Digital: 1.15V ~ 1.25V, 1.7V ~ 1.9V
- Packaging: Tray
- Reference Type: External, Internal
- Ratio - S/H:ADC: -
- Configuration: MUX-ADC
- Supplier Device Package: 198-NFBGA (9x15)
- Data Interface: LVDS - Serial
- Base Part Number: ADS52J
- Features: Simultaneous Sampling
- Number of Inputs: 8, 16, 32
- Mounting Type: Surface Mount
- Part Status: Active
- Package / Case: 198-LFBGA
- detail: 14 Bit Analog to Digital Converter 8, 16, 32 Input 16 Pipelined 198-NFBGA (9x15)
