دیتاشیت EMIF02-USB02F2
مشخصات دیتاشیت
| نام دیتاشیت |
EMIF02-USB02F2
|
| حجم فایل |
112.765
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
7
|
مشخصات
-
Manufacturer:
STMicroelectronics
-
Series:
IPAD™
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Obsolete
-
Type:
Low Pass
-
Filter Order:
2nd
-
Technology:
RC (Pi)
-
Number of Channels:
2
-
Center / Cutoff Frequency:
-
-
Attenuation Value:
-
-
Resistance - Channel (Ohms):
33, 1.3k, 10k
-
Values:
R = 33Ohms, 1.3kOhms, 10kOhms, C = 50pF
-
ESD Protection:
Yes
-
Operating Temperature:
-40°C ~ 85°C
-
Applications:
USB
-
Voltage - Rated:
-
-
Mounting Type:
Surface Mount
-
Package / Case:
10-WFBGA, FCBGA
-
Size / Dimension:
0.077" L x 0.064" W (1.97mm x 1.62mm)
-
Height:
0.028" (0.70mm)
-
Base Part Number:
EMIF02
-
detail:
RC (Pi) EMI Filter 2nd Order Low Pass 2 Channel R = 33Ohms, 1.3kOhms, 10kOhms, C = 50pF 10-WFBGA, FCBGA
