دیتاشیت EMIF04-MMC02F2
مشخصات دیتاشیت
| نام دیتاشیت |
EMIF04-MMC02F2
|
| حجم فایل |
138.665
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
8
|
مشخصات
-
Manufacturer:
STMicroelectronics
-
Series:
EMIF
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Obsolete
-
Type:
Low Pass
-
Filter Order:
2nd
-
Technology:
RC (Pi)
-
Number of Channels:
4
-
Center / Cutoff Frequency:
-
-
Attenuation Value:
-
-
Resistance - Channel (Ohms):
47, 13k, 56k
-
Values:
R = 47Ohms, 13kOhms, 56kOhms, C = 20pF
-
ESD Protection:
Yes
-
Operating Temperature:
-40°C ~ 85°C
-
Applications:
Data Lines for Mobile Devices
-
Voltage - Rated:
-
-
Mounting Type:
Surface Mount
-
Package / Case:
11-UFBGA, FCBGA
-
Size / Dimension:
0.080" L x 0.058" W (2.04mm x 1.47mm)
-
Height:
0.028" (0.70mm)
-
Base Part Number:
EMIF04
-
detail:
RC (Pi) EMI Filter 2nd Order Low Pass 4 Channel R = 47Ohms, 13kOhms, 56kOhms, C = 20pF 11-UFBGA, FCBGA
