دیتاشیت EMIF06-HMC01F2
مشخصات دیتاشیت
| نام دیتاشیت |
EMIF06-HMC01F2
|
| حجم فایل |
222.703
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
8
|
مشخصات
-
Manufacturer:
STMicroelectronics
-
Series:
IPAD™
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Discontinued at Digi-Key
-
Type:
Low Pass
-
Filter Order:
2nd
-
Technology:
RC (Pi)
-
Number of Channels:
6
-
Center / Cutoff Frequency:
-
-
Attenuation Value:
-
-
Resistance - Channel (Ohms):
50
-
Values:
R = 50Ohms, C = 20pF (Total)
-
ESD Protection:
Yes
-
Operating Temperature:
-40°C ~ 85°C
-
Applications:
Data Lines for Mobile Devices
-
Voltage - Rated:
-
-
Mounting Type:
Surface Mount
-
Package / Case:
16-WFBGA, FCBGA
-
Size / Dimension:
0.076" L x 0.076" W (1.92mm x 1.92mm)
-
Height:
0.028" (0.70mm)
-
Base Part Number:
EMIF06
-
detail:
RC (Pi) EMI Filter 2nd Order Low Pass 6 Channel R = 50Ohms, C = 20pF (Total) 16-WFBGA, FCBGA
