DAC7741 Datasheet دیتاشیت

DAC7741 Datasheet

مشخصات دیتاشیت

نام دیتاشیت DAC7741 Datasheet
حجم فایل 1016.013 کیلوبایت
نوع فایل pdf
تعداد صفحات 23

دانلود دیتاشیت DAC7741 Datasheet

دانلود دیتاشیت

سایر مستندات

DAC7741YB/250 23 pages

مشخصات فنی

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
  • Datasheet: Texas Instruments DAC7741YC/250
  • Interface: Parallel
  • Resolution: 16Bit
  • Output Type: Voltage-缓冲
  • Settling Time: 5us
  • Supply Voltage: 5V
  • Integral nonlinearity: ±3LSB;±1LSB
  • Operating Temperature: -40°C~+85°C
  • Package: LQFP-48(7x7)
  • Manufacturer: Texas Instruments
  • Voltage - Supply, Analog: ±11.4V ~ 15.75V, -4.75V ~ -15.75V
  • Supplier Device Package: 48-LQFP (7x7)
  • Data Interface: Parallel
  • Number of D/A Converters: 1
  • Mounting Type: Surface Mount
  • Number of Bits: 16
  • Architecture: R-2R
  • Voltage - Supply, Digital: 5V
  • Packaging: Cut Tape (CT)
  • Differential Output: No
  • Reference Type: External, Internal
  • Series: -
  • Package / Case: 48-LQFP
  • INL/DNL (LSB): ±3 (Max), ±1 (Max)
  • Base Part Number: DAC7741
  • Part Status: Active
  • detail: 16 Bit Digital to Analog Converter 1 48-LQFP (7x7)
