مشاهده دیتاشیت LMG3410R050RWHT	دانلود دیتاشیت

RoHS: true
Feature: Overcurrent Protection(OCP);Thermal Protection(OPT)
Category: Power Supply Chip/Gate Drive ICs
Datasheet: Texas Instruments LMG3410R050RWHT
Supply Voltage: 9.5V~18V
Operating Temperature: -40°C~+125°C@(Tj)
Package: QFN-32-EP(8x8)
Manufacturer: Texas Instruments
Current - Output / Channel: -
Current - Peak Output: -
Supplier Device Package: 32-VQFN (8x8)
Applications: General Purpose
Output Configuration: Half Bridge (2)
Load Type: Inductive, Capacitive
Features: Bootstrap Circuit
Fault Protection: Over Current, Over Temperature, UVLO
Voltage - Load: 400V
Mounting Type: Surface Mount
Voltage - Supply: 9.5V ~ 18V
Interface: Logic, PWM
Packaging: Cut Tape (CT)
Rds On (Typ): 57mOhm
Series: -
Package / Case: 32-VQFN Exposed Pad
Base Part Number: LMG341
Part Status: Active
Technology: Gallium Nitride (GaN) FETs
detail: Half Bridge (2) Driver General Purpose Gallium Nitride (GaN) FETs 32-VQFN (8x8)
