TN805-600H Datasheet

TN805/815, TS820, TYN608

Datasheet specifications

Datasheet's name TN805/815, TS820, TYN608
File size 243.988 KB
File type pdf
Number of pages 17

Download Datasheet TN805/815, TS820, TYN608

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Voltage - Off State: 600V
  • Voltage - Gate Trigger (Vgt) (Max): 1.3V
  • Current - Gate Trigger (Igt) (Max): 5mA
  • Voltage - On State (Vtm) (Max): 1.6V
  • Current - On State (It (AV)) (Max): 5A
  • Current - On State (It (RMS)) (Max): 8A
  • Current - Hold (Ih) (Max): 25mA
  • Current - Off State (Max): 5µA
  • Current - Non Rep. Surge 50, 60Hz (Itsm): 70A, 73A
  • SCR Type: Standard Recovery
  • Operating Temperature: -40°C ~ 125°C
  • Mounting Type: Through Hole
  • Package / Case: TO-251-3 Short Leads, IPak, TO-251AA
  • Supplier Device Package: I-PAK
  • Base Part Number: TN805
  • detail: SCR 600V 8A Standard Recovery Through Hole I-PAK
