دیتاشیت LM2901N/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LM139/239/339/2901/3302 |
|---|---|
| حجم فایل | 2478.873 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 32 |
دانلود دیتاشیت LM139/239/339/2901/3302 |
LM139/239/339/2901/3302 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Operational Amplifier/Comparator/Comparators
- Datasheet: Texas Instruments LM2901N/NOPB
- Output Type: 开集;轨到轨
- Supply Voltage: 2V~36V;1V~18V
- Number of Elements: -
- Operating Temperature: -40°C~+85°C
- Input Bias Current (Ib): 0.25uA
- Input Offset Voltage (Vos): 7mV
- Input Hysteresis Voltage (Vhys): -
- Common Mode Rejection Ratio (CMRR): -
- Package: PDIP-14
- Manufacturer: Texas Instruments
- Voltage - Input Offset (Max): 7mV @ 30V
- Type: General Purpose
- Supplier Device Package: 14-DIP
- Mounting Type: Through Hole
- Current - Quiescent (Max): 2.5mA
- Propagation Delay (Max): -
- Current - Input Bias (Max): 0.25µA @ 5V
- Base Part Number: LM2901
- Packaging: Tube
- Hysteresis: -
- Series: -
- Current - Output (Typ): 16mA @ 5V
- CMRR, PSRR (Typ): -
- Part Status: Active
- Package / Case: 14-DIP (0.300", 7.62mm)
- Voltage - Supply, Single/Dual (±): 2V ~ 36V, ±1V ~ 18V
- detail: Comparator General Purpose CMOS, DTL, ECL, MOS, Open-Collector, TTL 14-DIP
