STEVAL-ISA015V2 数据手册
其他文档
技术规格
- Manufacturer: STMicroelectronics
- Series: -
- Part Status: Obsolete
- Main Purpose: AC/DC, Primary Side
- Outputs and Type: 1, Isolated
- Power - Output: 100W
- Voltage - Output: 24V
- Current - Output: 4.3A
- Voltage - Input: 320 ~ 480 VAC
- Regulator Topology: Flyback
- Frequency - Switching: 50 ~ 85kHz
- Board Type: Fully Populated
- Supplied Contents: Board(s)
- Utilized IC / Part: L6565, STC04IE170HV
- detail: L6565, STC04IE170HV - AC/DC, Primary Side 1, Isolated Outputs Evaluation Board
