- Datasheet BAS69
BAS69-05WFILM Datasheet
Datasheet specifications
| Datasheet's name | BAS69 |
|---|---|
| File size | 101.8 KB |
| File type | |
| Number of pages | 9 |
Download Datasheet BAS69 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: STMicroelectronics
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Obsolete
- Diode Configuration: 1 Pair Common Cathode
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 15V
- Current - Average Rectified (Io) (per Diode): 10mA (DC)
- Voltage - Forward (Vf) (Max) @ If: 570mV @ 10mA
- Speed: Small Signal =< 200mA (Io), Any Speed
- Current - Reverse Leakage @ Vr: 230nA @ 15V
- Operating Temperature - Junction: 150°C (Max)
- Mounting Type: Surface Mount
- Package / Case: SC-70, SOT-323
- Supplier Device Package: SOT-323
- Base Part Number: BAS69
- detail: Diode Array 1 Pair Common Cathode Schottky 15V 10mA (DC) Surface Mount SC-70, SOT-323
