دیتاشیت TLV75801PDBVT

مشخصات دیتاشیت

دانلود دیتاشیت TLV758P Datasheet	TLV758P Datasheet Datasheet

RoHS: true
Category: Power Supply Chip/Linear Voltage Regulators (LDO)
Datasheet: Texas Instruments TLV75801PDBVT
Output Type: Adjustable
Output Current: 500mA
Output Voltage: 0.55V~5.5V
Dropout Voltage: 0.88V@(500mA)
Output Polarity: positive
Number of Outputs: 1
Maximum Input Voltage: 6V
Operating Temperature: -40°C~+125°C@(Tj)
Quiescent Current (Ground Current): 35uA
Package: SOT-23-5
Manufacturer: Texas Instruments
Base Part Number: TLV758
Supplier Device Package: SOT-23-5
Voltage - Output (Max): 5.5V
Output Configuration: Positive
Current - Quiescent (Iq): 35µA
PSRR: 50dB ~ 30dB (1kHz ~ 1MHz)
Voltage Dropout (Max): 0.88V @ 500mA
Number of Regulators: 1
Mounting Type: Surface Mount
Packaging: Cut Tape (CT)
Voltage - Output (Min/Fixed): 0.55V
Protection Features: Over Current, Over Temperature, Under Voltage Lockout (UVLO)
Series: -
Voltage - Input (Max): 6V
Current - Output: 500mA
Part Status: Active
Package / Case: SC-74A, SOT-753
Control Features: Enable
detail: Linear Voltage Regulator IC 1 Output 500mA SOT-23-5
