دیتاشیت HCF4027BEY

مشخصات دیتاشیت

دانلود دیتاشیت HCF4027B	HCF4027B Datasheet

Manufacturer: STMicroelectronics
Series: 4000B
Packaging: Tube
Part Status: Obsolete
Function: Set(Preset) and Reset
Type: JK Type
Output Type: Differential
Number of Elements: 2
Number of Bits per Element: 1
Clock Frequency: 24MHz
Max Propagation Delay @ V, Max CL: 90ns @ 15V, 50pF
Trigger Type: Positive Edge
Current - Output High, Low: 6.8mA, 6.8mA
Voltage - Supply: 3V ~ 20V
Current - Quiescent (Iq): 20µA
Input Capacitance: 5pF
Operating Temperature: -55°C ~ 125°C (TA)
Mounting Type: Through Hole
Supplier Device Package: 16-DIP
Package / Case: 16-DIP (0.300", 7.62mm)
Base Part Number: HCF4027
detail: Flip Flop 2 Element JK Type 1 Bit Positive Edge 16-DIP (0.300", 7.62mm)
