- دیتاشیت SN74LVC2G74QDCURQ1
SN74LVC2G74QDCURQ1 دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | SN74LVC2G74QDCURQ1 |
|---|---|
| حجم فایل | 63.619 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 14 |
دانلود دیتاشیت SN74LVC2G74QDCURQ1 |
دانلود دیتاشیت |
|---|
سایر مستندات
SN74LVC2G74-Q1 14 pages
مشخصات فنی
- RoHS: true
- Type: D-Type
- Series: 74LVC
- Category: Logic ICs/Flip Flops
- Function: 置位和复位
- Datasheet: Texas Instruments SN74LVC2G74QDCURQ1
- Output Type: Differential
- Sink Current: 24mA
- Trigger Type: 上升沿
- Source Current: 24mA
- Supply Voltage: 1.65V~5.5V
- Clock Frequency: 140MHz
- Input Capacitance: 5pF
- Quiescent Current (Iq): 10uA
- Maximum Propagation Delay: 5.4ns@5V,50pF
- Package: VSSOP-8
- Manufacturer: Texas Instruments
- Number of Elements: 1
- Operating Temperature: -40°C ~ 125°C (TA)
- Supplier Device Package: 8-VSSOP
- Current - Output High, Low: 24mA, 24mA
- Voltage - Supply: 1.65V ~ 5.5V
- Current - Quiescent (Iq): 10µA
- Mounting Type: Surface Mount
- Packaging: Cut Tape (CT)
- Number of Bits per Element: 1
- Max Propagation Delay @ V, Max CL: 5.4ns @ 5V, 50pF
- Base Part Number: SN74LVC2G
- Part Status: Active
- Package / Case: 8-VFSOP (0.091", 2.30mm Width)
- detail: Flip Flop 1 Element D-Type 1 Bit Positive Edge 8-VFSOP (0.091", 2.30mm Width)
