دیتاشیت LM1117T-ADJ/NOPB

LM1117

مشخصات دیتاشیت

نام دیتاشیت LM1117
حجم فایل 2762.122 کیلوبایت
نوع فایل pdf
تعداد صفحات 36

دانلود دیتاشیت LM1117

LM1117 Datasheet

مشخصات

  • Control Features: -
  • Base Part Number: LM1117
  • Package / Case: TO-220-3
  • Current - Supply (Max): 10mA
  • Part Status: Obsolete
  • Current - Output: 800mA
  • PSRR: 75dB (120Hz)
  • Series: -
  • Voltage - Output (Min/Fixed): 1.25V
  • Mounting Type: Through Hole
  • Number of Regulators: 1
  • Current - Quiescent (Iq): 5mA
  • Output Configuration: Positive
  • Voltage Dropout (Max): 1.2V @ 800mA
  • Operating Temperature: 0°C ~ 125°C
  • Supplier Device Package: TO-220-3
  • Protection Features: Over Current, Over Temperature
  • Manufacturer: Texas Instruments
  • Voltage - Input (Max): 15V
  • Output Type: Adjustable
  • Packaging: Tube
  • Voltage - Output (Max): 13.8V
  • detail: Linear Voltage Regulator IC 1 Output 800mA TO-220-3
