CD54,74HC(T)107 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
CD54,74HC(T)107
|
|
حجم فایل
|
994.938
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
18
|
مشخصات فنی
-
RoHS:
true
-
Type:
JK-Type
-
Series:
74HCT
-
Category:
Logic ICs/Flip Flops
-
Function:
Reset
-
Datasheet:
Texas Instruments CD74HCT107E
-
Output Type:
互补型
-
Sink Current:
4mA
-
Trigger Type:
下降沿
-
Source Current:
4mA
-
Supply Voltage:
4.5V~5.5V
-
Clock Frequency:
56MHz
-
Input Capacitance:
10pF
-
Number of Elements:
2
-
Operating Temperature:
-55°C~+125°C
-
Quiescent Current (Iq):
4uA
-
Maximum Propagation Delay:
43ns@4.5V,50pF
-
Number of Bits per Element:
1
-
Package:
PDIP-14
-
Manufacturer:
Texas Instruments
-
Supplier Device Package:
14-PDIP
-
Current - Output High, Low:
4mA, 4mA
-
Voltage - Supply:
4.5V ~ 5.5V
-
Current - Quiescent (Iq):
4µA
-
Mounting Type:
Through Hole
-
Packaging:
Tube
-
Max Propagation Delay @ V, Max CL:
43ns @ 4.5V, 50pF
-
Base Part Number:
74HCT107
-
Part Status:
Active
-
Package / Case:
14-DIP (0.300", 7.62mm)
-
detail:
Flip Flop 2 Element JK Type 1 Bit Negative Edge 14-DIP (0.300", 7.62mm)
