CD74HCT85E دیتاشیت

CD74HCT85E

مشخصات دیتاشیت

نام دیتاشیت CD74HCT85E
حجم فایل 73.064 کیلوبایت
نوع فایل pdf
تعداد صفحات 30

دانلود دیتاشیت CD74HCT85E

دانلود دیتاشیت

سایر مستندات

CD54,74HC(T)85 21 pages

مشخصات فنی

  • RoHS: true
  • Output: Active High
  • Category: Logic ICs/Digital Comparators
  • Datasheet: Texas Instruments CD74HCT85E
  • Sink Current: 4mA
  • Source Current: 4mA
  • Supply Voltage: 4.5V~5.5V
  • Output Function: AB
  • Quiescent Current: 8uA
  • Number of Channels: 4
  • Operating Temperature: -55°C~+125°C
  • Maximum Propagation Delay: 40ns@4.5V,50pF
  • Package: PDIP-16
  • Manufacturer: Texas Instruments
  • Type: Magnitude Comparator
  • Supplier Device Package: 16-PDIP
  • Current - Quiescent (Iq): 8µA
  • Current - Output High, Low: 4mA, 4mA
  • Mounting Type: Through Hole
  • Number of Bits: 4
  • Packaging: Tube
  • Voltage - Supply: 4.5V ~ 5.5V
  • Series: 74HCT
  • Max Propagation Delay @ V, Max CL: 40ns @ 4.5V, 50pF
  • Package / Case: 16-DIP (0.300", 7.62mm)
  • Base Part Number: 74HCT85
  • Part Status: Active
  • detail: Magnitude Comparator Bit Active High Output AB 16-PDIP
