CSD18537NKCS دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
CSD18537NKCS
|
|
حجم فایل
|
435.457
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
10
|
مشخصات فنی
-
Series:
-
-
Technology:
MOSFET (Metal Oxide)
-
Rds On (Max) @ Id, Vgs:
14mOhm @ 25A, 10V
-
Supplier Device Package:
TO-220-3
-
Package / Case:
TO-220-3
-
Packaging:
Tube
-
FET Feature:
-
-
Vgs (Max):
±20V
-
Part Status:
Active
-
Gate Charge (Qg) (Max) @ Vgs:
18nC @ 10V
-
Mounting Type:
Through Hole
-
Current - Continuous Drain (Id) @ 25°C:
50A (Tc)
-
Input Capacitance (Ciss) (Max) @ Vds:
1480pF @ 30V
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Manufacturer:
Texas Instruments
-
Drain to Source Voltage (Vdss):
60V
-
Vgs(th) (Max) @ Id:
3.5V @ 250µA
-
Power Dissipation (Max):
94W (Tc)
-
Drive Voltage (Max Rds On, Min Rds On):
6V, 10V
-
Base Part Number:
CSD18537
-
FET Type:
N-Channel
-
detail:
N-Channel 60V 50A (Tc) 94W (Tc) Through Hole TO-220-3
