دیتاشیت VND10B

VND10B

مشخصات دیتاشیت

نام دیتاشیت VND10B
حجم فایل 222.437 کیلوبایت
نوع فایل pdf
تعداد صفحات 13

دانلود دیتاشیت VND10B

VND10B Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Switch Type: General Purpose
  • Number of Outputs: 2
  • Ratio - Input:Output: 1:1
  • Output Configuration: High Side
  • Output Type: N-Channel
  • Interface: On/Off
  • Voltage - Load: 6V ~ 26V
  • Voltage - Supply (Vcc/Vdd): Not Required
  • Current - Output (Max): 3.4A
  • Rds On (Typ): 100mOhm (Max)
  • Input Type: Non-Inverting
  • Features: Status Flag
  • Fault Protection: Open Load Detect, Over Temperature
  • Operating Temperature: -40°C ~ 150°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: 5-PENTAWATT
  • Package / Case: Pentawatt-5 (Vertical, Bent and Staggered Leads)
  • Base Part Number: VND10
  • detail: Power Switch/Driver 1:1 N-Channel 3.4A 5-PENTAWATT
