TDA7499 Datasheet

TDA7499

Datasheet specifications

Datasheet's name TDA7499
File size 234.209 KB
File type pdf
Number of pages 5

Download Datasheet TDA7499

Download Datasheet

Other documentations

TDA7499 9 pages

Technical specifications

  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Type: Class AB
  • Output Type: 2-Channel (Stereo)
  • Max Output Power x Channels @ Load: 10W x 2 @ 8Ohm
  • Voltage - Supply: 10V ~ 36V, ±5V ~ 18V
  • Features: Depop, Mute, Short-Circuit and Thermal Protection, Standby
  • Mounting Type: Through Hole
  • Operating Temperature: 0°C ~ 70°C (TA)
  • Supplier Device Package: 11-Multiwatt
  • Package / Case: Multiwatt-11 (Vertical, Bent and Staggered Leads)
  • Base Part Number: TDA7499
  • detail: Amplifier IC 2-Channel (Stereo) Class AB 11-Multiwatt
