STC5DNF30V دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
STC5DNF30V
|
|
حجم فایل
|
331.907
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
12
|
مشخصات فنی
-
Manufacturer:
STMicroelectronics
-
Series:
STripFET™
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
FET Type:
2 N-Channel (Dual)
-
FET Feature:
Logic Level Gate
-
Drain to Source Voltage (Vdss):
30V
-
Current - Continuous Drain (Id) @ 25°C:
4.5A
-
Rds On (Max) @ Id, Vgs:
35mOhm @ 2.3A, 4.5V
-
Vgs(th) (Max) @ Id:
600mV @ 250µA
-
Gate Charge (Qg) (Max) @ Vgs:
11.5nC @ 4.5V
-
Input Capacitance (Ciss) (Max) @ Vds:
460pF @ 25V
-
Power - Max:
1.3W
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
8-TSSOP (0.173", 4.40mm Width)
-
Supplier Device Package:
8-TSSOP
-
Base Part Number:
STC5DNF
-
detail:
Mosfet Array 2 N-Channel (Dual) 30V 4.5A 1.3W Surface Mount 8-TSSOP
