دیتاشیت SN7432N
مشخصات دیتاشیت
| نام دیتاشیت | SN5432, SN54LS/S32, SN7432, SN74LS/S32 |
|---|---|
| حجم فایل | 1367.503 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 24 |
دانلود دیتاشیت SN5432, SN54LS/S32, SN7432, SN74LS/S32 |
SN5432, SN54LS/S32, SN7432, SN74LS/S32 Datasheet |
|---|
مشخصات
- RoHS: true
- Series: 7400
- Category: Logic ICs/Gates
- Datasheet: Texas Instruments SN7432N
- Sink Current: 16mA
- Source Current: 800uA
- Supply Voltage: 4.75V~5.25V
- Logic Gate Type: ORGate
- Number of Channels: 4
- Low Level Range (VIL): 0.8V
- Operating Temperature: 0°C~+70°C
- High Level Range (VIH): 2V
- Propagation Delay Time: 22ns@5V,15pF
- Quiescent Current (Max): 22mA
- Package: PDIP-14
- Manufacturer: Texas Instruments
- Logic Level - High: 2V
- Base Part Number: SN743
- Supplier Device Package: 14-PDIP
- Logic Level - Low: 0.8V
- Package / Case: 14-DIP (0.300", 7.62mm)
- Current - Quiescent (Max): 22mA
- Current - Output High, Low: 800µA, 16mA
- Features: -
- Mounting Type: Through Hole
- Packaging: Tube
- Voltage - Supply: 4.75V ~ 5.25V
- Number of Circuits: 4
- Max Propagation Delay @ V, Max CL: 22ns @ 5V, 15pF
- Number of Inputs: 2
- Part Status: Active
- Logic Type: OR Gate
- detail: OR Gate IC 4 Channel 14-PDIP
