BAS70-08SFILM Datasheet
Datasheet specifications
| Datasheet's name | BAS70 |
|---|---|
| File size | 184.232 KB |
| File type | |
| Number of pages | 14 |
Download Datasheet BAS70 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: STMicroelectronics
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Obsolete
- Diode Configuration: 3 Independent
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 70V
- Current - Average Rectified (Io) (per Diode): 70mA (DC)
- Voltage - Forward (Vf) (Max) @ If: 1V @ 15mA
- Speed: Small Signal =< 200mA (Io), Any Speed
- Current - Reverse Leakage @ Vr: 10µA @ 70V
- Operating Temperature - Junction: 150°C (Max)
- Mounting Type: Surface Mount
- Package / Case: 6-TSSOP, SC-88, SOT-363
- Supplier Device Package: SOT-323-6L
- Base Part Number: BAS70
- detail: Diode Array 3 Independent Schottky 70V 70mA (DC) Surface Mount 6-TSSOP, SC-88, SOT-363
