LM78S40CN/NOPB دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
LM78S40CN/NOPB
|
|
حجم فایل
|
23.675
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
12
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
Buck-boost type
-
Topology:
Step-down;Boost
-
Datasheet:
Texas Instruments LM78S40CN/NOPB
-
Output Type:
Adjustable
-
Input Voltage:
2.5V~40V
-
Output Voltage:
1.25V~40V
-
Number of Outputs:
1
-
Switching Frequency:
100kHz
-
Output Current (Max):
1.5A
-
Operating Temperature:
0°C~+70°C@(TA)
-
Synchronous Rectification:
NO
-
Package:
DIP-16
-
Manufacturer:
Texas Instruments
-
Package / Case:
16-DIP (0.300", 7.62mm)
-
Output Configuration:
Positive or Negative
-
Base Part Number:
LM78S40
-
Packaging:
Tube
-
Frequency - Switching:
100Hz ~ 100kHz
-
Supplier Device Package:
16-PDIP
-
Part Status:
Obsolete
-
Current - Output:
1.5A (Switch)
-
Series:
-
-
Voltage - Input (Max):
40V
-
Synchronous Rectifier:
No
-
Voltage - Output (Min/Fixed):
1.25V
-
Voltage - Input (Min):
2.5V
-
Mounting Type:
Through Hole
-
Voltage - Output (Max):
40V (Switch)
-
detail:
Buck, Boost Switching Regulator IC Positive or Negative Adjustable 1.25V 1 Output 1.5A (Switch) 16-DIP (0.300", 7.62mm)
