دیتاشیت TS420-700T

TS420

مشخصات دیتاشیت

نام دیتاشیت TS420
حجم فایل 1103.384 کیلوبایت
نوع فایل pdf
تعداد صفحات 14

دانلود دیتاشیت TS420

TS420 Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Voltage - Off State: 700V
  • Voltage - Gate Trigger (Vgt) (Max): 800mV
  • Current - Gate Trigger (Igt) (Max): 200µA
  • Voltage - On State (Vtm) (Max): 1.6V
  • Current - On State (It (AV)) (Max): 2.5A
  • Current - On State (It (RMS)) (Max): 4A
  • Current - Hold (Ih) (Max): 5mA
  • Current - Off State (Max): 5µA
  • Current - Non Rep. Surge 50, 60Hz (Itsm): 30A, 33A
  • SCR Type: Sensitive Gate
  • Operating Temperature: -40°C ~ 125°C
  • Mounting Type: Through Hole
  • Package / Case: TO-220-3
  • Supplier Device Package: TO-220AB
  • Base Part Number: TS420
  • detail: SCR 700V 4A Sensitive Gate Through Hole TO-220AB
