LM2941(C) دیتاشیت

LM2941(C)

مشخصات دیتاشیت

نام دیتاشیت LM2941(C)
حجم فایل 3327.917 کیلوبایت
نوع فایل pdf
تعداد صفحات 32

دانلود دیتاشیت LM2941(C)

دانلود دیتاشیت

سایر مستندات

LM2941LD/NOPB 33 pages

TO-220 Leadbend Options 10 pages

LM2941(C) 32 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Texas Instruments LM2941T/LF03
  • Output Type: Adjustable
  • Output Current: 1A
  • Output Voltage: 5V~20V
  • Dropout Voltage: 1V@(1A)
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 26V
  • Operating Temperature: -40°C~+125°C
  • Quiescent Current (Ground Current): 10mA
  • Package: TO-220-5
  • Manufacturer: Texas Instruments
  • Series: -
  • Voltage - Output (Max): 20V
  • Output Configuration: Positive
  • Voltage Dropout (Max): 1V @ 1A
  • Packaging: Tube
  • Voltage - Output (Min/Fixed): 5V
  • Protection Features: Over Temperature, Reverse Polarity, Short Circuit
  • PSRR: -
  • Supplier Device Package: TO-220-5
  • Current - Quiescent (Iq): 10mA
  • Base Part Number: LM2941
  • Mounting Type: Through Hole
  • Number of Regulators: 1
  • Voltage - Input (Max): 26V
  • Current - Output: 1A
  • Part Status: Active
  • Current - Supply (Max): 15mA
  • Control Features: Enable
  • Package / Case: TO-220-5 Formed Leads
  • detail: Linear Voltage Regulator IC 1 Output 1A TO-220-5
