دیتاشیت 74LVC1G123DCUTG4
مشخصات دیتاشیت
| نام دیتاشیت | SN74LVC1G123 Datasheet |
|---|---|
| حجم فایل | 1112.879 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 28 |
دانلود دیتاشیت SN74LVC1G123 Datasheet |
SN74LVC1G123 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Logic ICs/Monostable Multivibrators
- Datasheet: Texas Instruments 74LVC1G123DCUTG4
- Input Type: Schmitt Trigger
- Logic Family: 74LVC
- Sink Current: 32mA
- Source Current: 32mA
- Supply Voltage: 1.65V~5.5V
- Logic Gate Type: Monostable
- Propagation Delay: 18.5ns
- Number Of Channels: 1
- OperatingTemperature: -40°C~+125°C
- Package: VSSOP-8
- Manufacturer: Texas Instruments
- Base Part Number: 74LVC1
- Supplier Device Package: 8-VSSOP
- Schmitt Trigger Input: Yes
- Package / Case: 8-VFSOP (0.091", 2.30mm Width)
- Series: 74LVC
- Mounting Type: Surface Mount
- Packaging: Cut Tape (CT)
- Operating Temperature: -40°C ~ 125°C
- Current - Output High, Low: 32mA, 32mA
- Independent Circuits: 1
- Part Status: Active
- Logic Type: Monostable
- Voltage - Supply: 1.65V ~ 5.5V
- detail: Monostable Multivibrator 18.5ns 8-VSSOP
