دیتاشیت LM5021NA-1/NOPB

LM5021

مشخصات دیتاشیت

نام دیتاشیت LM5021
حجم فایل 5257.171 کیلوبایت
نوع فایل pdf
تعداد صفحات 36

دانلود دیتاشیت LM5021

LM5021 Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/AC-DC Controllers & Regulators
  • Topology: Flyback;Forward
  • Datasheet: Texas Instruments LM5021NA-1/NOPB
  • Duty Cycle: 80%
  • Supply Voltage: 8V~30V
  • Output Isolation: Isolation
  • Switching Frequency: 1MHz
  • Operating Temperature: -40°C~+125°C@(Tj)
  • Package: PDIP-8
  • Manufacturer: Texas Instruments
  • Voltage - Breakdown: -
  • Internal Switch(s): No
  • Base Part Number: LM5021
  • Fault Protection: Current Limiting, Over Load
  • Control Features: Frequency Control, Soft Start, Sync
  • Frequency - Switching: Up to 1MHz
  • Voltage - Supply (Vcc/Vdd): 8V ~ 30V
  • Supplier Device Package: 8-PDIP
  • Mounting Type: Through Hole
  • Part Status: Obsolete
  • Voltage - Start Up: 20V
  • Series: -
  • Package / Case: 8-DIP (0.300", 7.62mm)
  • Packaging: Tube
  • detail: Converter Offline Flyback, Forward Topology Up to 1MHz 8-PDIP
