TPS7A3725DRVT دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TPS7A3725DRVT
|
|
حجم فایل
|
73.494
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
33
|
مشخصات فنی
-
RoHS:
true
-
Feature:
Overcurrent Protection;Thermal Protection;Reverse connection protection;欠压锁定(UVLO)
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Texas Instruments TPS7A3725DRVT
-
Output Current:
1A
-
Output Voltage:
2.5V
-
Dropout Voltage:
0.2V@(1A)
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
5.5V
-
Operating Temperature:
-40°C~+125°C
-
Quiescent Current (Ground Current):
400uA
-
Power Supply Rejection Ratio (PSRR):
58dB@(100Hz)
-
Package:
DFN-6(2x2)
-
Manufacturer:
Texas Instruments
-
Series:
-
-
Voltage - Output (Max):
-
-
Output Configuration:
Positive
-
Output Type:
Fixed
-
Voltage Dropout (Max):
0.2V @ 1A
-
Packaging:
Cut Tape (CT)
-
Voltage - Output (Min/Fixed):
2.5V
-
Protection Features:
Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
-
PSRR:
58dB ~ 37dB (100Hz ~ 10kHz)
-
Supplier Device Package:
6-WSON (2x2)
-
Current - Quiescent (Iq):
400µA
-
Base Part Number:
TPS7A3
-
Mounting Type:
Surface Mount
-
Number of Regulators:
1
-
Voltage - Input (Max):
5.5V
-
Current - Output:
1A
-
Part Status:
Active
-
Current - Supply (Max):
1.3mA
-
Control Features:
Enable
-
Package / Case:
6-WDFN Exposed Pad
-
detail:
Linear Voltage Regulator IC 1 Output 1A 6-WSON (2x2)
