SN74LS266D دیتاشیت

SN74LS266D

مشخصات دیتاشیت

نام دیتاشیت SN74LS266D
حجم فایل 475.924 کیلوبایت
نوع فایل pdf
تعداد صفحات 9

دانلود دیتاشیت SN74LS266D

دانلود دیتاشیت

سایر مستندات

SN54LS266, SN74LS266 12 pages

SN74LS266N 13 pages

مشخصات فنی

  • RoHS: true
  • Series: 74LS
  • Category: Logic ICs/Gates
  • Datasheet: Texas Instruments SN74LS266D
  • Sink Current: 8mA
  • Source Current: -
  • Supply Voltage: 4.75V~5.25V
  • Logic Gate Type: XNOR NOR Gate
  • Number of Channels: 4
  • Low Level Range (VIL): 0.8V
  • Operating Temperature: 0°C~+70°C
  • High Level Range (VIH): 2V
  • Propagation Delay Time: 30ns@5V,15pF
  • Quiescent Current (Max): 13mA
  • Package: SOP-14
  • Manufacturer: Texas Instruments
  • Logic Level - High: 2V
  • Base Part Number: SN74LS26
  • Supplier Device Package: 14-SOIC
  • Logic Level - Low: 0.8V
  • Package / Case: 14-SOIC (0.154", 3.90mm Width)
  • Current - Quiescent (Max): 13mA
  • Current - Output High, Low: -, 8mA
  • Features: Open Collector
  • Mounting Type: Surface Mount
  • Packaging: Tube
  • Voltage - Supply: 4.75V ~ 5.25V
  • Number of Circuits: 4
  • Max Propagation Delay @ V, Max CL: 30ns @ 5V, 15pF
  • Number of Inputs: 2
  • Part Status: Active
  • Logic Type: XNOR (Exclusive NOR)
  • detail: XNOR (Exclusive NOR) IC 4 Channel Open Collector 14-SOIC
