STPS15SM80CR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
STPS15SM80C
|
|
حجم فایل
|
140.527
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
11
|
مشخصات فنی
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Obsolete
-
Diode Configuration:
1 Pair Common Cathode
-
Diode Type:
Schottky
-
Voltage - DC Reverse (Vr) (Max):
80V
-
Current - Average Rectified (Io) (per Diode):
7.5A
-
Voltage - Forward (Vf) (Max) @ If:
780mV @ 7.5A
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Current - Reverse Leakage @ Vr:
20µA @ 80V
-
Operating Temperature - Junction:
175°C (Max)
-
Mounting Type:
Through Hole
-
Package / Case:
TO-262-3 Long Leads, I²Pak, TO-262AA
-
Supplier Device Package:
I2PAK
-
Base Part Number:
STPS15
-
detail:
Diode Array 1 Pair Common Cathode Schottky 80V 7.5A Through Hole TO-262-3 Long Leads, I²Pak, TO-262AA
