EMIF07-LCD03F3 دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت EMIF07-LCD03F3	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Manufacturer: STMicroelectronics
Series: IPAD™
Packaging: Tube
Part Status: Obsolete
Type: Low Pass
Filter Order: 3rd
Technology: LC (Pi)
Number of Channels: 7
Center / Cutoff Frequency: -
Attenuation Value: -40dB @ 900MHz ~ 2GHz
Resistance - Channel (Ohms): -
Values: R = 125Ohms, C = 30pF (Total)
ESD Protection: Yes
Operating Temperature: -40°C ~ 85°C
Applications: Data Lines for Mobile Devices
Voltage - Rated: -
Mounting Type: Surface Mount
Package / Case: 18-WFBGA, FCBGA
Size / Dimension: 0.078" L x 0.062" W (1.97mm x 1.57mm)
Height: 0.026" (0.66mm)
Base Part Number: EMIF07
detail: LC (Pi) EMI Filter 3rd Order Low Pass 7 Channel R = 125Ohms, C = 30pF (Total) 18-WFBGA, FCBGA
