UCC28630D Datasheet
Datasheet specifications
|
Datasheet's name
|
UCC28630D
|
|
File size
|
97.817
KB
|
|
File type
|
pdf
|
|
Number of pages
|
86
|
Technical specifications
-
RoHS:
true
-
Category:
Power Supply Chip/AC-DC Controllers & Regulators
-
Topology:
Flyback
-
Datasheet:
Texas Instruments UCC28630D
-
Duty Cycle:
70%
-
Supply Voltage:
8V~20V
-
Output Isolation:
Isolation
-
Switching Frequency:
200Hz~120kHz
-
Operating Temperature:
-40°C~+125°C@(Tj)
-
Package:
SOP-7
-
Manufacturer:
Texas Instruments
-
Base Part Number:
UCC286
-
Mounting Type:
Surface Mount
-
Series:
-
-
Internal Switch(s):
No
-
Supplier Device Package:
7-SOIC
-
Voltage - Breakdown:
-
-
Power (Watts):
30W
-
Voltage - Start Up:
14.75V
-
Packaging:
Tube
-
Package / Case:
8-SOIC (0.154", 3.90mm Width), 7 Leads
-
Control Features:
-
-
Voltage - Supply (Vcc/Vdd):
8V ~ 20V
-
Frequency - Switching:
200Hz ~ 120kHz
-
Part Status:
Active
-
Fault Protection:
Current Limiting, Over Load, Over Temperature, Over Voltage
-
detail:
Converter Offline Flyback Topology 200Hz ~ 120kHz 7-SOIC
