دیتاشیت REG1117-2.85
مشخصات دیتاشیت
| نام دیتاشیت | REG1117(A) Datasheet |
|---|---|
| حجم فایل | 891.155 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 21 |
دانلود دیتاشیت REG1117(A) Datasheet |
REG1117(A) Datasheet Datasheet |
|---|
مشخصات
- Voltage - Input (Max): 15V
- Voltage - Output (Max): -
- Voltage Dropout (Max): 1.2V @ 800mA
- Operating Temperature: -40°C ~ 125°C
- Output Configuration: Positive
- Series: -
- Current - Quiescent (Iq): 10mA
- Manufacturer: Texas Instruments
- Base Part Number: REG111
- Supplier Device Package: SOT-223-4
- Mounting Type: Surface Mount
- Voltage - Output (Min/Fixed): 2.85V
- Number of Regulators: 1
- PSRR: 62dB (120Hz)
- Output Type: Fixed
- Package / Case: TO-261-4, TO-261AA
- Packaging: Tube
- Protection Features: Over Current, Over Temperature
- Control Features: -
- Part Status: Active
- Current - Output: 800mA
- detail: Linear Voltage Regulator IC 1 Output 800mA SOT-223-4
