دیتاشیت UCC28704EVM-724

UCC28704EVM-724 User Guide

مشخصات دیتاشیت

نام دیتاشیت UCC28704EVM-724 User Guide
حجم فایل 1381.188 کیلوبایت
نوع فایل pdf
تعداد صفحات 21

دانلود دیتاشیت UCC28704EVM-724 User Guide

UCC28704EVM-724 User Guide Datasheet

مشخصات

  • Regulator Topology: Flyback
  • Base Part Number: UCC287
  • Current - Output: 2A
  • Series: -
  • Board Type: Fully Populated
  • Manufacturer: Texas Instruments
  • Utilized IC / Part: UCC28704
  • Voltage - Input: 85 ~ 265 VAC
  • Power - Output: 10W
  • Main Purpose: AC/DC, Primary Side
  • Voltage - Output: 5V
  • Supplied Contents: Board(s)
  • Frequency - Switching: -
  • Part Status: Active
  • Outputs and Type: 1, Isolated
  • detail: UCC28704 - AC/DC, Primary Side 1, Isolated Outputs Evaluation Board
