CSD86356Q5DT دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت CSD86356Q5D Datasheet	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Base Part Number: CSD8635
Gate Charge (Qg) (Max) @ Vgs: 7.9nC @ 4.5V, 19.3nC @ 4.5V
Operating Temperature: -55°C ~ 150°C (TJ)
Package / Case: 8-PowerTDFN
Series: NexFET™
Input Capacitance (Ciss) (Max) @ Vds: 1.04nF @ 12.5V, 2.51nF @ 12.5V
Vgs(th) (Max) @ Id: 1.85V @ 250µA, 1.5V @ 250µA
Current - Continuous Drain (Id) @ 25°C: 40A (Ta)
Power - Max: 12W (Ta)
Supplier Device Package: 8-VSON-CLIP (5x6)
Mounting Type: Surface Mount
Drain to Source Voltage (Vdss): 25V
Rds On (Max) @ Id, Vgs: 4.5mOhm @ 20A, 5V, 0.8mOhm @ 20A, 5V
Part Status: Active
Packaging: Cut Tape (CT)
Manufacturer: Texas Instruments
FET Feature: Logic Level Gate, 5V Drive
FET Type: 2 N-Channel (Half Bridge)
detail: Mosfet Array 2 N-Channel (Half Bridge) 25V 40A (Ta) 12W (Ta) Surface Mount 8-VSON-CLIP (5x6)
