- دیتاشیت TLC1543CN
TLC1543CN دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | TLC1543CN |
|---|---|
| حجم فایل | 76.899 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 22 |
دانلود دیتاشیت TLC1543CN |
دانلود دیتاشیت |
|---|
سایر مستندات
TLC1542I/M/Q/C, TLC1543C/I/Q 37 pages
TLC1543CN 35 pages
مشخصات فنی
- RoHS: true
- Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
- Datasheet: Texas Instruments TLC1543CN
- Interface: SPI
- resolution: 10Bit
- Supply Voltage: 5V
- number of channels: 11
- sampling frequency: 38kHz
- Operating Temperature: 0°C~+70°C
- Package: PDIP-20
- Manufacturer: Texas Instruments
- Input Type: Single Ended
- Packaging: Tube
- Series: -
- Number of A/D Converters: 1
- Number of Inputs: 11
- Features: Selectable Address
- Ratio - S/H:ADC: 1:1
- Supplier Device Package: 20-PDIP
- Data Interface: SPI
- Package / Case: 20-DIP (0.300", 7.62mm)
- Sampling Rate (Per Second): 38k
- Configuration: MUX-S/H-ADC
- Part Status: Active
- Base Part Number: TLC154
- Architecture: SAR
- Reference Type: External
- Mounting Type: Through Hole
- Number of Bits: 10
- Voltage - Supply, Analog: 5V
- Voltage - Supply, Digital: 5V
- detail: 10 Bit Analog to Digital Converter 11 Input 1 SAR 20-PDIP
